The PSI KIT-1037 Engine Controller Kit is an all-in-one solution for LS/LT engine swap and conversion projects. This kit includes everything needed — harness, PCM, and accessories — for a complete, plug-and-play engine and transmission conversion.
Application
- 2008, 2009, 2010, 2011, 2012, 2013, 2014 58X Corvette/Camaro LS, Vortec Truck, LS3, LH6, LY5, LMG, LH8, LY6, L96, L92, L9H, L76, L77, L99, LS3, LS7, LS376 480 & 525 GM Crate engines with T56, TR6060 manual, and non-electronic transmissions.
- CLICK FOR COMPONENT ID GUIDE
- SEE DESCRIPTION BELOW FOR INCLUDED PARTS
Kit Includes
- Complete Engine Wiring Harness (4 Wire Hookup), Programmed Engine Controller (PCM-1009), Accelerator Pedal (ACC-1007), LS3 Cartridge Mass Air Flow Sensor (ACC-1005), Mass Air Flow Sensor Holder, Oxygen Sensors x2 (ACC-1003)
Notes
These harnesses are designed for retrofitting '08 - '13 LS3 engines (Corvette, Camaro, Crate Engines) and T56/TR6060 or non-electronic automatic transmissions into older muscle cars and street rods or newer non-emissions controlled vehicles. They are completely plug and play with four wire hookup (switched power, constant power and ground connections required). Harnesses are professionally constructed from Brand New GM Delphi Connectors and TXL (Polyethylene Cross Linked) High Temperature Wire to GM Specifications. All Harnesses are 100% Quality Inspected prior to shipping. Please contact PSI with any questions. Harnesses are designed with a sliding grommet seal and 4 - 5 feet of length from the rear of the cylinder head to the PCM mounting position under the vehicle dashboard. A sliding grommet seal allows for professional, leak proof installation. Harnesses are professionally constructed from Brand New GM Delphi Connectors and TXL (Polyethylene Cross Linked) High Temperature Wire to GM Specifications. All harnesses are 100% Quality Inspected prior to shipping. Note that harnesses are for non-emissions equipped vehicles and do not include air pump or EGR provisions. Please contact PSI for more information.
