The Dakota Digital SEN-03-6 Metric Adaptor Bushing Kit allows 1/8" NPT male sensors to be installed into metric-threaded ports, providing a reliable, leak-free connection between Dakota Digital pressure and temperature senders and metric-equipped engines and components.
Each bushing is CNC machined from high-quality brass stock for precise threads and long-term durability, and aluminum crush washers are included with the kit to ensure a proper seal at installation.
Key Features
- CNC machined brass construction for durability and precise fit
- Converts 1/8" NPT male sensors to common metric thread sizes
- Aluminum crush washers included for a proper, leak-free seal
- Compatible with Dakota Digital pressure and temperature senders
Specifications
- Part Number: SEN-03-6
- Bushing Sizes Included: 10mm x 1.5, 12mm x 1.5, 14mm x 1.5, 16mm x 1.5, 1/8"-28 BSP
- 10mm x 1.5: accommodates pressure sensors
- 12mm x 1.5: accommodates pressure and Dakota Digital 2-wire temperature sensors
- 14mm x 1.5: accommodates both pressure and temperature sensors
- 16mm x 1.5: accommodates both pressure and temperature sensors
- 1/8"-28 BSP: accommodates pressure sensors
Kit Includes
- Five metric adaptor bushings (10mm x 1.5, 12mm x 1.5, 14mm x 1.5, 16mm x 1.5, 1/8"-28 BSP)
- Aluminum crush washers
