Description
Description:
- Horsepower & Torque: 365 Horsepower / 365 FT LBS
- Compression Ratio: 9.5:1
- Aluminum Heads
- Hydraulic Roller Cam
- Cast Crank
- Hypereutectic Pistons
Block:
- BluePrint Engines High Strength Cast Iron Block
- Increased Deck Thickness and Strength Webbing
- Priority Main Oiling
- 4.000" Bore
- 4-Bolt Main
- 1-Piece Rear Main Seal
- Improved Water Jacket Design
Rotating Assembly:
- Cast Crankshaft
- 3.000" Stroke
- OEM Type 5.090" Connecting Rods
- Hypereutectic Pistons
- 50oz Externally Balanced Front and Rear
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads -HP9009
- 60cc Chamber
- 2.02" Intake / 1.60" Exhaust Valves
- 190cc Intake / 60cc Exhaust Runners
Cam Specs:
- Hydraulic Roller
- .533 Intake / .544 Exhaust Lift
- 215 Intake / 220 Exhaust Duration
- @.050-114 Degree Lobe Separation
Ignition Timing:
- 10-16 Degrees Initial, 32-34 Total
Also Includes:
- Bronco Script Valve Covers
- Harmonic Balancer
- Dual Plane, Satin Aluminum Intake Manifold
- Holley Sniper 2 EFI System
- Distributor
- Dual/Rear Sump Oil Pan
Notes:
- Recommended break in oil for your BluePrint Crate Engine: BPP710
- Not for EGR
- Push in Valve Cover Breather not included. BluePrint Engines recommends PN B6AZ-6766-B or similar
- Click Here for BluePrint Engines Ford Serpentine System with PS and AC
- Click Here for BluePrint Engines Ford Serpentine System with PS
- Holley Sniper EFI is NOT compatible with AOD trans. It does NOT have AOD kick down lever.
